Features

• IP65 waterproof and dustproof making the inverter suitable for various working conditions.
• Configurable color with the built-in RGB LED bar.
• Built-in Wi-Fi for mobile monitoring (APP is required).
• Built-in alternative port for generator and emergent load.
• Optional external CT sensor to guarantee 100% self-consumption.
• Programmable supply priority for PV, Battery or Grid.
• Built-in communication port for BMS (RS485).
• User-adjustable charging current and voltage.
• Parallel operation up to 6 units.

Specifications

• General

  • Maximum PV Input Power: 7500W
  • Rated Output Power: 6000VA/6000W
  • Parallel Capability: Yes, 6 units

• Input

  • Maximum DC Voltage: 600VDC
  • Start-up Voltage/Initial Feeding Voltage: 120VDC/160VDC
  • MPPT Voltage Range: 120VDC-550VDC
  • Frequency Range: 50Hz/60Hz (Auto detection)

• Output

  • Output Voltage Waveform: Pure Sine Wave
  • Nominal Output Voltage: 120VAC (P-N)/208VAC (P-P)/240VAC (P-P)
  • Output Voltage Range: 105.5–132VAC per phase
  • Nominal Output Current: 25A per phase

• Battery

  • Battery Voltage: 40–62VDC
  • Maximum Charging Current: 120A
  • Efficient (DC to AC): 91%

• Operating Environment

  • Operating Temperature Range: -13°F to 140°F (>113°F derating)

• Physical

  • Dimension: 8.5x20.3x27.6in/215.5x515x700mm
  • Net Weight: 90.4lb/41kg
